The working principle and characteristics of ultrasonic cleaning machine are briefly introduced


Ultrasonic cleaning technology, the use of ultrasonic cavitation on the surface of the dirt on the object to impact, Peel, to achieve the goal of cleaning. The utility model has the advantages of a high cleaning degree, fast cleaning speed, etc. . Especially for blind holes and various geometric objects, other cleaning means can not achieve the cleaning effect. So, today, let's talk about ultrasonic cleaning machines!

40KHZ, 80KHZ, and 100KHZ automatic conversion of three frequency settings; rough cleaning, cleaning, cleaning, and cleaning products all kinds of dead corners. This product is designed to meet the needs of hospital endoscope room cleaning ultrasonic cleaning equipment. The utility model is mainly suitable for cleaning the operation equipment of medical institutions, such as endoscopic biopsy forceps, hard endoscopes, scalpels, hemostatic forceps, etc. . It is the special equipment for the operating room, endoscope center, and disinfection supply center of the medical institution. Ultrasonic cleaning is not suitable for rubber, plastic, silica gel, optical lens, fiber, gold-plated, optical cables, and other soft materials and coating materials.

Working principle: ultrasonic cleaner is the use of ultrasonic power generated by different frequencies of vibration signals, through the sensor into high-frequency oscillation of ultrasonic cavitation effect. Ultrasonic cavitation: high-frequency oscillating signal from an ultrasonic power supply is transmitted to the sensor, converted to high-frequency oscillations, and propagated vertically in the cleaning fluid in alternating and alternating densities, in the density region (that is, negative pressure region), tens of thousands of small air bubbles are produced by pulling off water molecules, which turn to the density region (that is, positive pressure region) and quickly close and break up, which is called ultrasonic cavitation effect. In this process, the burst cavitation bubble can produce more than 100 instantaneous high pressure. Continuous cavitation high pressure is like a series of small explosions that constantly affect the surface of the object, so that the surface of the object and the gap in the rapid exfoliation of dirt, achieve the goal of surface purification.

Product parameters

Working power supply: AC220V ± 22V50Hz ± 1Hz

Ultrasound frequency: 40KHz80KHz100KHz maximum ultrasound

Power: 9000W (adjustable power)

Equipment Power: 4KW

Tank Volume: 43L

Procedures: P 1 single-frequency cleaning, p 2 multi-frequency cleaning, p 3 manual cleaning, P 4 custom cleaning

Functions: automatic feed, automatic drainage, automatic heating, automatic feed enzyme, automatic frequency switch

Note: the size of the ultrasonic groove is the same as the single frequency matching size of the workstation.

Product characteristics

1. Automatic operation: the equipment has the functions of automatic water intake, automatic circulation heating, ultrasonic wave, automatic drainage, and automatic enzyme addition.

2. Multiple procedures: four automatic control procedures: single-frequency cleaning, multi-frequency cleaning, custom cleaning, and manual cleaning.

3. Operation Control System: PLC control system, seven-inch color touch screen operation system.

Four. Multiple frequencies: 403 ultrasonic frequency KHz, 80KHz, 100KHz, one machine single frequency, one machine dual frequency, and one machine triple frequency cleaning methods can be combined.

5. Circulation heating: circulation pump with a washing function, can be inside the pipe cavity of the dirty washing out of the pipe cavity.

6. Integrated ultrasonic power supply: driven by high-power equipment imported from Japan, with strong output power. Adopting the radical control line, the ultrasonic density is greatly improved, the cleaning work is more even and the cleaning degree is higher.

Parameter characteristics

1. The frequency of ultrasonic cleaning is 40 kHz, 80 kHz, and 100 kHz. The cleaning methods of one single frequency, one dual frequency, and one triple frequency can be combined respectively.

2. To avoid equipment damage, use a hidden heating method to achieve automatic heating, and the cleaning temperature can be adjusted.

3. The cleaning agent can be released automatically according to the proportion of the cleaning agent.

Four. The ultrasonic power can be adjusted by touch screen in real-time, the range of power adjustment is 1% ~ 100%.

5. PLC system with 5-control system with 7-inch color touch screen, temperature, time, ultrasonic frequency, and ultrasonic power real-time display, and through password adjustment.

6. The equipment has four preset programs: single-frequency, multi-frequency, manual and custom program. You can quickly select the cleaning methods of different programs.

Seven. With automatic water, drainage, cycle heating, ultrasound, automatic enzyme function, and fully automatic control.

8th uses the circulation pump cycle heating, which has a flushing function.

9. Adopt an integrated ultrasonic generator, adopt imported components as ultrasonic power supply, ultrasonic frequency more stable.
