Brief description: single tank ultrasonic cleaning machine

Return



1. Model: LANJ-X series

2. Ultrasonic frequency: 28kHz, 40KHz

3. Ultrasonic output power: 300W ~ 3600W

4. Power supply voltage: AC 220V / 240V, 1, 15 AMP ~AC 220V / 240V, 1, 15Amp

5. Heat heat power: 1.5KW ~ 4.5KW

6. Maximum capacity of the cleaning tank: 23L ~ 126L

Remarks: Re -customized according to needs


Overview:


1. Single-slot ultrasonic cleaning machine is suitable for special equipment for small parts cleaning. The equipment is simple, easy to operate, and small in shape. It has been widely shuttled into all walks of life. It becomes an important process for various manufacturers to produce products. It can reduce costs, and improve quality for manufacturers. It can bring supreme reputation to all walks of life. The favor of users from all walks of life. So the single slot ultrasound cleaning machine won the favor of users from all walks of life.


2. Principle of ultrasonic cleaning machine: The high-frequency oscillating signal sent by the ultrasonic generator is transformed into a medium through the conversion of high-frequency mechanical oscillations-the corresponding cleaning solvent. The ultrasonic wave in the cleaning solution is densely related to Radon forward to make the liquid flow into tens of thousands of tiny bubbles. These air bubbles form and grow in the negative pressure zone formed by the vertical transmission of ultrasonic waves. "In the process of effect, the closing of bubbles can form an instantaneous high pressure of more than 1,000 atmospheric pressure, just like a series of small" explosions ". It constantly impacts the surface of the object, so that the dirt on the surface of the object and the gap quickly strips off. To achieve the purpose of the surface purification of the object's surface essence.


3. Compared with other kinds of cleaning methods, the ultrasonic cleaning machine has shown great advantages, especially in specialized, group-oriented production enterprises. Ultrasonic cleaning machine has gradually replaced the traditional immersion cleaning, pressure cleaning, steam cleaning, and steam cleaning process methods. The high efficiency and cleanliness of the ultrasonic cleaning machine are due to the penetrating and cavitating shock wave produced by the sound wave propagating in the medium. So it is easy to clean the parts with complicated shapes, inner cavities, and fine holes, for general oil removal, rust prevention, and phosphating process.  Under the Sonication, it can be completed in just two or three minutes. Its speed than the traditional method can be increased several times to dozens of times. The cleanliness can also meet high standards. This in many of the product surface quality and productivity requirements of the occasion, more prominent shows that other treatment methods are difficult to achieve or have irreplaceable results. This is on the occasion when the quality and productivity requirements of the product surface are high. And it is more prominently showing the results that it is difficult to achieve or unhappy with other treatment methods.


The features of single slot ultrasonic cleaning machine:


1. Use alcohol or ordinary tap water plus a little additive as a cleaning agent. The cost is low and the cleaning effect is good

2. The cleaning effect of high power converters, strong ultrasound power

3. Can work continuously for a long time to adapt to batch production

4. Advanced third-generation generator, better efficiency, higher frequency, and better quality

5. Automatic constant temperature system adjustable room temperature

6. Thicked stainless steel, beautiful and durable


Main applications of single tank ultrasonic cleaning machine:


An ultrasonic cleaning machine is suitable for cleaning all kinds of work. For example electronic parts, electroplating, hardware, watches, watchbands, tools, optical lenses, jewelry, lenses, glasses frame, half-body silicon, spinneret filter and glassware, and other cleanings.
